Features:
1. Optimize the imaging effect within the working range of 600mm color selection standard.
2. M42*1 threaded interface, with the adapter interface can be matched with all kinds of interfaces.
型号
Model
F50DMB28
F50DMB40
F50DMB28
F50DMB40
焦距(mm)
Focal Length
50mm 50mm
50mm 50mm 标准放大倍率
Standad Magnificaition
0.0946 0.094 0.0946 0.094 像面尺寸(mm)
Image Size
φ30 φ30 φ30 φ30 光圈
Iris(F)
F2.8 F4 F2.8 F4
光学畸变
Optical Distortion
-0.61% -0.61% -0.61% -0.61% 相对照度(%)
Relative Illuminace
95.5% 95.5% 95.5% 95.5% 工作距离(mm)
Working Distance
574 574 574 574 最优工作距离(mm)
Optimal Working Distance
600mm-700mm 600mm-700mm 600mm-700mm 600mm-700mm 接口
Mount
M42*1 M42*1 M42*1 M42*1 法兰距(mm)
Flange Length
12 12 5.9 5.9 分辨率
Resolution
5.5K 5μ 5.5K 5μ 5.5K 5μ 5.5K 5μ -
-
